M5Stack's M5Dial: A Breakthrough in IoT Rotary Control Devices

The world of IoT (Internet of Things) is ever-evolving, with innovations emerging at every corner. One such groundbreaking product that has recently caught the attention of tech enthusiasts and developers alike is the M5Dial. Launched by the renowned M5Stack, this smart rotary control device is not just another addition to the IoT landscape; it promises to redefine how we perceive and interact with smart devices.

Shop Now
@electromaker.io Rotary encoder, touch screen, RFID, Wifi and Bluetooth! #arduino #raspberrypi #esp32 #maker #smarthome #homeautomation #diyelectronics #coding #engineering ♬ original sound - Electromaker

Equipped with a vibrant color touchscreen display and based on the company's M5StampS3 module, the M5Dial is more than just a rotary control device. It's a testament to M5Stack's commitment to pushing the boundaries of technology, offering a blend of functionality, aesthetics, and user experience. Whether you're a developer looking to integrate it into your next project or a tech aficionado eager to explore its features, the M5Dial promises a journey worth embarking on.

Features of the M5Dial

At first glance, the M5Dial might seem like a simple rotary control device, but a closer look reveals a plethora of features that set it apart. Here's a breakdown of its standout attributes:

  • 1.28-inch Round TFT Touchscreen: A vibrant display that offers users a seamless interaction experience. Whether you're adjusting settings or navigating through options, the touchscreen ensures precision and clarity.
  • Rotary Encoder: Beyond the touchscreen, the M5Dial boasts a rotary encoder, allowing for intuitive control and navigation. This feature is particularly useful for applications that require fine-tuned adjustments.
  • RFID Detection Module: In the realm of smart home applications, RFID plays a pivotal role. The M5Dial's integrated RFID module can detect and interact with RFID tags, paving the way for a myriad of automation and control scenarios.
  • RTC Circuit and Buzzer: Time-sensitive tasks are a breeze with the M5Dial's Real-Time Clock (RTC) circuit. Paired with an in-built buzzer, it can serve as a reminder or alert system for various applications.
  • Under-Screen Buttons: For those who prefer tactile feedback, the M5Dial comes equipped with under-screen buttons, offering an alternative mode of interaction.

Each feature of the M5Dial has been thoughtfully integrated, ensuring that it caters to a wide range of applications and user preferences. Whether it's for a DIY project or a commercial IoT solution, the M5Dial stands ready to elevate the user experience.

Shop Now


The Core of M5Dial: M5StampS3 Module

We stock M5 Stack products in the Electomaker Store!

While the M5Dial boasts an impressive array of features, its true prowess lies in its core: the M5StampS3 module. This module is the heartbeat of the device, powering its functionalities and ensuring optimal performance.

The M5StampS3 module is built around the Espressif ESP32-S3 microcontroller, a powerhouse in the world of IoT. Here's a closer look at its specifications:

  • Dual-core Tensilica Xtensa LX7 32-bit Processor: Running at up to 240MHz, this processor ensures that the M5Dial operates smoothly, handling multiple tasks with ease.
  • Integrated Memory: With 512kB of static RAM (SRAM), 8MB of pseudo-static RAM (PSRAM), and 8MB of SPI flash, the M5Dial is equipped to store and retrieve data efficiently.
  • Wi-Fi and Bluetooth Low Energy (BLE) Radio: Connectivity is key in the world of IoT, and the M5Dial doesn't disappoint. Whether it's connecting to other devices via Bluetooth or accessing the internet through Wi-Fi, the M5Dial ensures seamless communication.

With the M5StampS3 module at its core, the M5Dial is not just a device; it's a testament to M5Stack's commitment to innovation and excellence. By harnessing the power of the Espressif ESP32-S3 microcontroller, the M5Dial promises reliability, efficiency, and unparalleled performance.

m5-dial-electromaker-showWe featured the M5 Dial in this episode of The Electromaker Show!

Additional Components and User Experience

The M5Dial is more than just its core module. M5Stack has meticulously integrated additional components to enhance the device's functionality and user experience. Here's a deeper dive into these components:

  • 1.28" Color Touchscreen Display: Offering a resolution of 240×240, this display is based on the GC9A01 display and FT3267 touch drivers. It provides users with a clear and vibrant visual experience, making interactions intuitive and enjoyable.
  • Rotary Encoder Ring: Surrounding the touchscreen is a moveable ring that triggers a rotary encoder input. This unique design choice allows users to make precise adjustments and navigate menus with ease.
  • 13.56MHz RFID Tag Reader: Embedded behind the screen, this RFID reader adds another layer of functionality, enabling the M5Dial to detect and interact with RFID tags seamlessly.
  • Power Options: For projects requiring mobility, the M5Dial supports an optional battery. Charging is made convenient through a USB Type-C connector or the board's 6-36VDC power input, ensuring the device remains powered for extended durations.

Every component of the M5Dial has been integrated with the user in mind. From its vibrant display to its intuitive rotary encoder, the device promises a user experience that is both enriching and seamless. Whether you're a developer looking to integrate the M5Dial into your project or a tech enthusiast exploring its features, the device promises an interaction that is both memorable and efficient.

Shop Now

Pricing and Availability

With its plethora of features and cutting-edge technology, one might wonder about the cost of owning an M5Dial. M5Stack has priced the M5Dial competitively at $34.90, ensuring that it remains accessible to a wide range of users.

For those eager to get their hands on this innovative device, the M5Dial is available for purchase from the Electromaker store. However, due to its popularity and high demand, stocks might be limited. It's advisable to check the store regularly for availability updates or subscribe to notifications to stay informed.

If you are interested in the wide range of cool products available from M5Stack then take a look at the Electomaker Store.
