Acoustic Levitation

Photo of Club_Asimov

Made by Club_Asimov / Robotics

About the project

We built another levitation machine with 72 ultrasonic transducers. We want to show that robotics and science can be really cool!

Project info

Difficulty: Moderate

Platforms: Arduino

Estimated time: 7 hours

License: GNU General Public License, version 3 or later (GPL3+)

Like

Items used in this project

Hardware components

	This Is A Time Saving Kit Of Jumper Wires - Cut Stripped And Pre-bent For Your Prototyping Pleasure. Included With This Kit Are 14 Various Lengths Of 22awg Wire - 2 5 7 10 12 15 17 20 22 25 50 75 100 And 125mm - 10 Pieces Of Each.inclu	x 1
	Arduino Nano 3.0 (with Atmega328)	x 1
	L298 Dual H-bridge Motor Driver	x 1
	3D printed TinyLev https://www.thingiverse.com/thing:2766680	x 1
	Sensors Transducers	x 72
	Push-button Power Switch Breakout	x 1

Software apps and online services

Arduino

Hand tools and fabrication machines

	Glue gun	x 1
	Soldering iron	x 1

Story

Today with an Arduino, a 3D printer and information found online, its possible to make extroardinary machines.

We built a levitation machine that uses 72 ultrasonic transducers. The transducers work at 40 kHz and can trap objects with a density greater than2.2g/cm3 and a diameter of 4mm.

The levitation of water, paper and styrophoamspheres is possible and shown in this video.

https://www.facebook.com/ClubAsimov/videos/1977110885917161/

Now you can get all the components in this kit: https://www.makerfabs.com/index.php?route=product/product&product_id=508

Tinylev Stand https://www.thingiverse.com/thing:2766680

Complete tutorial https://www.instructables.com/id/Acoustic-Levitator/

We want to show you once again that robotics and science can be reallycool!

Schematics, diagrams and documents

Acoustic levitation schema

Code

Acoustic levitation

#include <avr/sleep.h>
#include <avr/power.h>

#define N_PORTS 1
#define N_DIVS 24

#define WAIT_LOT(a) __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");__asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");__asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");__asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop")
#define WAIT_MID(a) __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");__asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");__asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop")
#define WAIT_LIT(a) __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop"); __asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop");  __asm__ __volatile__ ("nop")


#define OUTPUT_WAVE(pointer, d)  PORTC = pointer[d*N_PORTS + 0]

#define N_BUTTONS 6
//half a second
#define STEP_SIZE 1
#define BUTTON_SENS 2500
#define N_FRAMES 24

static byte frame = 0;
static byte animation[N_FRAMES][N_DIVS] =
{{0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa},
{0x9,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x6,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa},
{0x9,0x9,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x6,0x6,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa},
{0x9,0x9,0x9,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x6,0x6,0x6,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa},
{0x9,0x9,0x9,0x9,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x6,0x6,0x6,0x6,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa},
{0x9,0x9,0x9,0x9,0x9,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x6,0x6,0x6,0x6,0x6,0xa,0xa,0xa,0xa,0xa,0xa,0xa},
{0x9,0x9,0x9,0x9,0x9,0x9,0x5,0x5,0x5,0x5,0x5,0x5,0x6,0x6,0x6,0x6,0x6,0x6,0xa,0xa,0xa,0xa,0xa,0xa},
{0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x5,0x5,0x5,0x5,0x5,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0xa,0xa,0xa,0xa,0xa},
{0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x5,0x5,0x5,0x5,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0xa,0xa,0xa,0xa},
{0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x5,0x5,0x5,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0xa,0xa,0xa},
{0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x5,0x5,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0xa,0xa},
{0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x5,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0xa},
{0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6},
{0x5,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0xa,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6},
{0x5,0x5,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0xa,0xa,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6},
{0x5,0x5,0x5,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0xa,0xa,0xa,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6},
{0x5,0x5,0x5,0x5,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0xa,0xa,0xa,0xa,0x6,0x6,0x6,0x6,0x6,0x6,0x6,0x6},
{0x5,0x5,0x5,0x5,0x5,0x9,0x9,0x9,0x9,0x9,0x9,0x9,0xa,0xa,0xa,0xa,0xa,0x6,0x6,0x6,0x6,0x6,0x6,0x6},
{0x5,0x5,0x5,0x5,0x5,0x5,0x9,0x9,0x9,0x9,0x9,0x9,0xa,0xa,0xa,0xa,0xa,0xa,0x6,0x6,0x6,0x6,0x6,0x6},
{0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x9,0x9,0x9,0x9,0x9,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0x6,0x6,0x6,0x6,0x6},
{0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x9,0x9,0x9,0x9,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0x6,0x6,0x6,0x6},
{0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x9,0x9,0x9,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0x6,0x6,0x6},
{0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x9,0x9,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0x6,0x6},
{0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x5,0x9,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0xa,0x6}};


void setup()
{

/*
 for (int i = 0; i < (N_PORTS*N_DIVS); ++i){
    animation[frame][i] =  0;
  }

  for (int i = 0; i < (N_PORTS*N_DIVS/2); ++i){
     animation[frame][i] = 0b11111111;
  }

  for(int i = 0; i < N_DIVS; ++i){
    if (i % 2 == 0){
      animation[frame][i * N_PORTS] |= 0b00000001;
    }else{
      animation[frame][i * N_PORTS] &= 0b11111110;
    }
  }
*/
   DDRC = 0b00001111; //A0 to A3 are the signal outputs
   PORTC = 0b00000000;

   pinMode(10, OUTPUT); //pin 10 (B2) will generate a 40kHz signal to sync
   pinMode(11, INPUT_PULLUP); //pin 11 (B3) is the sync in
   //please connect pin 10 to pin 11

   for (int i = 2; i < 8; ++i){ //pin 2 to 7 (D2 to D7) are inputs for the buttons
    pinMode(i, INPUT_PULLUP);
   }

  // generate a sync signal of 40khz in pin 10
  noInterrupts();           // disable all interrupts
  TCCR1A = bit (WGM10) | bit (WGM11) | bit (COM1B1); // fast PWM, clear OC1B on compare
  TCCR1B = bit (WGM12) | bit (WGM13) | bit (CS10);   // fast PWM, no prescaler
  OCR1A =  (F_CPU / 40000L) - 1;
  OCR1B = (F_CPU / 40000L) / 2;
  interrupts();             // enable all interrupts

  // disable everything that we do not need
  ADCSRA = 0;  // ADC
  power_adc_disable ();
  power_spi_disable();
  power_twi_disable();
  power_timer0_disable();
  //power_usart0_disable();
  Serial.begin(115200);

 byte* emittingPointer = &animation[frame][0];
 byte buttonsPort = 0;

 bool anyButtonPressed;
 bool buttonPressed[N_BUTTONS];
 short buttonCounter = 0;

  LOOP:
    while(PINB & 0b00001000); //wait for pin 11 (B3) to go low

    OUTPUT_WAVE(emittingPointer, 0); buttonsPort = PIND; WAIT_LIT();
    OUTPUT_WAVE(emittingPointer, 1); anyButtonPressed = (buttonsPort & 0b11111100) != 0b11111100; WAIT_MID();
    OUTPUT_WAVE(emittingPointer, 2); buttonPressed[0] = buttonsPort & 0b00000100; WAIT_MID();
    OUTPUT_WAVE(emittingPointer, 3); buttonPressed[1] = buttonsPort & 0b00001000; WAIT_MID();
    OUTPUT_WAVE(emittingPointer, 4); buttonPressed[2] = buttonsPort & 0b00010000; WAIT_MID();
    OUTPUT_WAVE(emittingPointer, 5); buttonPressed[3] = buttonsPort & 0b00100000; WAIT_MID();
    OUTPUT_WAVE(emittingPointer, 6); buttonPressed[4] = buttonsPort & 0b01000000; WAIT_MID();
    OUTPUT_WAVE(emittingPointer, 7); buttonPressed[5] = buttonsPort & 0b10000000; WAIT_MID();
    OUTPUT_WAVE(emittingPointer, 8); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 9); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 10); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 11); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 12); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 13); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 14); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 15); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 16); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 17); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 18); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 19); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 20); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 21); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 22); WAIT_LOT();
    OUTPUT_WAVE(emittingPointer, 23);


    if( anyButtonPressed ){
       ++buttonCounter;
       if (buttonCounter > BUTTON_SENS){
        buttonCounter = 0;

        if (! buttonPressed[0] ) {
          if( frame < STEP_SIZE ) {
            frame = N_FRAMES-1;
         }else{
            frame-=STEP_SIZE;
         }
        }
        else if (! buttonPressed[1] ) {
          if ( frame >= N_FRAMES-STEP_SIZE ) {
            frame = 0;
          }else {
            frame+=STEP_SIZE;
          }
       }else if (! buttonPressed[2] ) {
          frame = 0;
       }
        emittingPointer = & animation[frame][0];
       }
    }else {
      buttonCounter = 0;
    }

  goto LOOP;

}

void loop(){}
