Ulabel: Finger Labeling Device

About the project

5-finger Machine Learning Labeling Device for Supervised Learning of prosthetic sensors (finger movement prediction from forearm tendon muscles).

Project info

Difficulty: Moderate

Estimated time: 2 weeks

License: GNU General Public License, version 3 or later (GPL3+)

Items used in this project

Hardware components

Power Switch Power Switch On/Off switch x 1
JST Battery Connector JST Battery Connector x 1
Battery Battery Evaluation, Demonstration Kits, Boards and Modules / Evaluation Kits, Boards and Modules x 1
M2 Screws M2 Screws 2mmx10mm x 3
6mm Tactile Push Button Switches 6mm Tactile Push Button Switches x 4
Hall Effect Sensor Hall Effect Sensor 49E SS49E Linear Hall Sensor x 4
MakerFocus 3.7 Charge Circuit MakerFocus 3.7 Charge Circuit With protection x 1
128x32 OLED 128x32 OLED SSD1306 OLED Screen x 1
D'Addario Hand Exerciser D'Addario Hand Exerciser 4 Piston Spring Grip x 1
ESP32-S2 ESP32-S2 Mini by Wemos x 1

View all

Story

The uLabel, formerly known as the LASK4 system, represents a significant evolution in hand movement and force measurement technology. This project is a joint endeavor between Ultimate Robotics and Open Muscle, showcasing our commitment to advancing somatosensory devices.






Details

Introduction: The uLabel system, an evolution of the LASK4 device, is a groundbreaking project jointly developed by Ultimate Robotics and Open Muscle. It's designed to measure the movement and force of all five fingers, expanding its capabilities beyond the original four-finger design.

Key Features:

  • Five-Finger Measurement: Enhanced from the LASK4's four-finger model, uLabel accurately measures all five fingers.
  • Somatosensory Feedback: As a somatosensory device, it provides real-time feedback for hand rehabilitation, enhancing the user's recovery journey.
  • D'Addario Finger Training Integration: Maintains the use of the D'Addario finger training device, ensuring consistent quality and user experience.
  • Customizable Components: Comes with custom 3D STL file add-ons and a specially designed PCB for precise movement and force measurement.
  • Machine Learning Applications: Ideal for feature data labeling in machine learning, it plays a crucial role in AI research and development.

Technical Specifications:

  • Connectivity: The uLabel system utilizes UDP packets via the ESP32-S2 for transmitting sensor data to an accompanying computer.
  • Software: The system operates on micropython, embracing open-source and open-hardware principles. This facilitates widespread innovation and adaptability, allowing others to build upon and enhance the design.
  • Versatility: Initially aimed at hand rehabilitation, uLabel's potential extends to labeling training data for the Open Muscle Band in the prosthetics biometric sensor domain. Its adaptable design hints at future applications for measuring movement and force in other body parts.

Explore More: For a deeper insight into uLabel's capabilities in machine learning and hand rehabilitation, check out our latest video featuring the system in action. Stay updated with our project's progress and access all necessary resources on our GitHub page.



 The device was designed to label the training data accumulated by theOpen Muscle Band but as been designed to work with uMyo by Ultimate Robotics as well as any other forearm muscle sensing device.

Check out the latest video showing the LASK system being used in machine learning for open muscle!

LASK4 Github

The uLabel Version Zero prototype was sponsored by PCBWay!




Project Logs

Video Update on LASK and AI Training Use for Prosthetic Sensors


LASK as a Machine Learning Labeler to Successfully Detect Finger Curls

In this study, we present a novel and cost-effective method for detecting individual finger movements using a custom pressure sensor array based on Hall effect sensors and magnets. Twelve sensors were placed radially around the forearm, and machine learning techniques, specifically a random forest regressor, were employed to distinguish between finger curls. With only 5 minutes of training data, our approach achieved a mean absolute error (MAE) of 35, demonstrating its potential as a viable and inexpensive sensor solution for finger movement and force detection. This forearm armlet-based system has applications in fields such as prosthetics, robotics, and human-computer interaction, offering a promising alternative to traditional sensor technologies.

Introduction

Hand amputations can significantly impact an individual’s quality of life and ability to perform daily tasks. Despite losing their hand, many people with amputations retain an intact forearm with functional muscle movement. However, due to the disconnected tendons, detecting and interpreting finger movements becomes challenging. In this study, we sought to develop an innovative and cost-effective sensor solution that could discern individual finger movements by sampling the force exerted by muscle contractions in the forearm. One of our main challenges was finding a low-pressure sensor system with minimal friction. We explored different designs and ultimately used a spring and clevis pin system for the best results, while also considering rubber foam for a more scalable solution in future designs.

We hypothesized that with minimal training data, our approach could provide an inexpensive and accessible solution for a wide range of individuals who could potentially benefit from this technology. To test our hypothesis, we conducted experiments on able-bodied individuals with the intention of validating the efficacy of our approach and warranting further research in the context of hand amputees. Our work was conducted using open-source and open hardware principles to contribute to the scientific community with a non-proprietary alternative to existing forearm sensor technologies. This open approach aims to foster collaboration, innovation, and widespread adoption of our proposed forearm bracelet system.

In this paper, we describe the design and implementation of our custom pressure sensor array, the machine learning techniques employed to recognize finger movements, and the performance of our system in detecting individual finger curls. We also discuss potential applications of our technology in prosthetics, robotics, and human-computer interaction, as well as future directions for research and development.

Materials & Methods Pressure Sensors:

Custom pressure sensors were designed using Hall Effect sensors mounted on printed circuit boards (PCBs). These PCBs were attached to PLA 3D printed clevis pin holders, which featured a hole for the clevis pin piston positioned 7mm above the Hall Effect sensor. A nail head “foot” was secured to the piston, and a 5mm diameter earth magnet was glued to the foot. The piston was fitted into the clevis pin holder, and a spring and clip were attached to the opposite side. The feet were designed to make contact with the skin, and their surface area could be adjusted to modify the sensor’s overall amplitude.

A second version of the sensor utilized the same PCB but incorporated a rubber foam spring system, a rubber sheet, and a magnet. This alternative design yielded promising results and is recommended for further investigation, as its construction requires less time.

Sensor Array and Data Acquisition: The magnet array was wired together and connected to an ESP32-S2 microcontroller, which utilized MicroPython firmware and its 20 13-bit ADCs to measure the Hall sensor values.

Prototype Version 5.3.0 with the Clevis Pin Piston. Sensor consist of a hall effect sensor on a PCB, a clevis pin holder made of PLA. A magnet on the head of the clevis pin, a 20gm Cherry keyboard spring, clevis pin pin, and a foot made of PLA to increase the surface area of the skin contact surface. Machine Learning Model

Data Collection:

A Python UDP server was used to collect data from the sensor array band. The data was labeled using a Label Seeking (LASK) system, which was built on a rehabilitation device that consisted of four pistons with springs designed to strengthen the muscles responsible for finger movements. Hall Effect sensors were also incorporated into the LASK system. By providing labels to the machine learning regressor, the LASK system enabled us to identify the specific finger movements we were attempting to recognize.

Model Training:

The Scikit-Learn Python library was employed for machine learning model development. A random forest regressor was selected for training the data due to its versatility and robustness in handling complex relationships between input features and output predictions. The labeled data collected from the LASK system was used to train the random forest regressor, which aimed to identify and distinguish individual finger movements based on the pressure sensor data obtained from the forearm.

Data Collection and Transmission

The 12 sensor data points, along with the corresponding time data, were transmitted over UDP packets to a central computer running a collection server. Simultaneously, the LASK system, responsible for applying labels to the training data, sent its 4 sensor readings, time data, and processor ticks.

Data Pairing and Preprocessing

The data was saved in a JSON format and then passed through a sorting algorithm to match the pairs of data points based on their closest proximity in time. Unmatched data points were discarded. The paired data was then converted into a CSV format to be used as input for the random forest training program in Python.

Feature Selection and Dataset Preparation

The Open Muscle and LASK data pair CSV file was processed to create a feature dataset with 13 attributes, comprising 12 sensor data points and 1 time data point from the Open Muscle system, and a labeled dataset with 5 attributes, including 4 sensor data points and 1 time data point from the LASK system.

Model Training and Evaluation

The random forest regressor was trained using the prepared feature and labeled datasets. An 80/20 split was applied to the original dataset for training and testing purposes. The model’s performance was assessed using mean absolute error (MAE) as a metric. The MAE was found to have an average of 40, with a range between 25-80, depending on the quality of the data.

Testing with Prerecorded and Live Data

To further evaluate the model’s performance, tests were conducted on both prerecorded and live data. The random forest regressor demonstrated its capability to accurately detect finger movements in real-time scenarios, thereby showcasing its potential as a viable and cost-effective sensor solution for finger movement and force detection.

Live predictions of the small random forest regressor model. The bottom 12 rows are the 12 Open Muscle Sensors. The top 4 rows are the LASK system readings. Cyan is the actual signal from the LASK, Yellow is the prediction from the model. The model was trained on ‘capture_11’ on the github repository. This image shows a good example of the output from 5 minutes of training data, with detectable signals and some noise. The lask system, and open muscle band (not seen and behind the camera), being tested live in a demo.

Training dataset with the best results was taken during a recording that was posted on youtube:

Video of the data from this training set: https://github.com/turfptax/openmuscle/blob/main/MachineLearning/January23.csv

We also tested a version that used foam instead of springs.

Open Muscle 5.6 with foam sensors instead of springs. LASK4 labeling system V2.0 Initial Test Results

All files needed to test the data found in the demo folder on the GitHub repository.

https://github.com/turfptax/openmuscle/tree/main/Demo

Results for Training on capture_11.csv (~5 minutes of data)

  • Mean Squared Error: 7689.885189928801
  • Mean Absolute Error: 29.919568537049315

Results for Training on January23.csv (~10 minutes of data)

All of the files are available on github to train the model and run the predictions. https://github.com/turfptax/openmuscle/tree/main/Demo

The results for the training on January 23rd were also manually split up into sections and fed into the random forest regressor to ensure that there was not an error with the data split. The data yielded the same results.

predictions_vs_actualsDownload
predictions_vs_actuals-Short-SegmentDownload
predictions_vs_actuals-Short-Segment_shorterDownload

Detecting Finger Movement with Machine Learning Example of extremely accurate predictions done with random movements (no scripted movement for finger curls). Example of both a single finger detection and Mutiple finger curl detections.

LASK Successful Use in Machine Learning

We were exited to post our preliminary tests with the LASK4v2 and OM12.

Since the LASK system is relatively simple and the data is clean it works great for machine learning.

Here you see the LASK being used to train and to verify the predictions of a machine learning model.


LASK4 Version 2 Updates

LASK4v2 Works and Charges the Battery this time!
The signals are clean and the micropython code works well. Started my initial data acquisition for open muscle using the LASK4 as the main controller.


Code

LASK4 Repo

Open Muscle Repo

Includes demo files and virtual devices for people to train their own model without having the hardware. Check out the demo folder

LASK4

Includes the PCB gerber files along with all of the documentation.
